The SUB 10.17 EDGE is a compact yet powerful subwoofer designed for outstanding performance in both music and home cinema systems. Powered by advanced ICEpower technology it delivers 700W RMS and a peak of 1045Wproviding deep extension explosive dynamics and precise control.
Its ultra-light rigid driver developed from our acclaimed Cinema series ensures fast accurate responsemaking it agile enough for detailed music playback while delivering the depth and power needed for immersive movie experiences.With flexible tuning options and a heavily braced cabinet for maximum stability the SUB 10.17 EDGE offers exceptional speed power and precisionsetting a new benchmark for performance and value in its class.
30-Day Money Back Guarantee
Lifetime Customer Support
Including VAT (0%) $0.00
undefined
Currently unavailable
700W ICEpower® Class-D Amplifier with DSP
Deep Bass Extension Down to 20Hz
EQ & Custom Port Tuning for Room Matching
1045W Peak Power for Explosive Dynamics
Cinema Series Driver for Extreme Precision
XLR + RCA Inputs for Studio Compatibility
The SUB 10.17 EDGE uses a custom-designed 10" driver derived from the XTZ Cinema Series. Its lightweight long-fiber pulp cone, ultra-long stroke geometry, and advanced suspension system deliver deep, tight, and responsive bass without distortion—even under high excursion conditions.
Long-stroke fiber cone
Reinforced for stiffness and speed, enabling clean, controlled low-frequency output.
High-precision motor system
Sealed design with aluminum shorting ring reduces distortion and maintains linearity.
KLIPPEL-optimized suspension
Supports extreme cone travel while preserving control and mechanical stability.
At the back sits the SA-1 amplifier, based on ICEpower® Class D architecture. With 700W RMS and 1045W peak, it delivers high dynamic output while maintaining clarity at all levels. The integrated DSP and PEQ allow detailed fine-tuning, and its fast response ensures tight bass that follows the source signal precisely.
700W RMS output, 117 dB SNR
Reference-grade dynamic performance with ultra-low noise and distortion.
Advanced DSP with PEQ
Enables precision adjustment using factory presets or custom EQ curves.
XLR and RCA connectivity
Balanced and unbalanced inputs ensure clean signal integration in any setup.
The 10.17 EDGE uses a sealed enclosure made from 25 mm MDF with internal bracing and damping. Its compact size and low-reflective matte finish make it easy to integrate into most environments, while rounded edges contribute to a modern, understated design.
25 mm braced MDF panels
Heavy, rigid construction eliminates cabinet resonance.
Acoustically optimized sealed volume
Ensures accurate transient response and natural low-end behavior.
Matte black finish with rounded edges
Discreet and installation-friendly in both dedicated and shared spaces.
Whether you're integrating into a home cinema or a stereo setup, the SUB 10.17 EDGE provides multiple tools to shape bass response. These include three factory-tuned EQ profiles, a fully adjustable parametric EQ, and a flexible port system. Together, they allow you to adapt the subwoofer’s performance to your room acoustics, speaker setup, and personal preference.
Multiple tuning options
EQ presets, PEQ, and port modes offer different paths to optimize for room and taste.
Designed for flexibility
Works equally well in small to large rooms and can be tailored to suit your priorities for music or film playback.
The onboard DSP includes three selectable EQ profiles to quickly adapt the subwoofer to your room or content. Each preset adjusts the system's frequency response and extension characteristics.
REF
Flat response for full-range extension and maximum fidelity.
EQ1
Slightly reduced low-end extension for tighter bass and boundary compensation.
EQ2
Boosted upper bass for more punch and energy in dynamic content.
The built-in PEQ lets you correct a room-induced peak or null with precision. It allows manual adjustment of frequency, Q (bandwidth), and gain to achieve a smoother in-room response.
Adjustable frequency range
Target a frequency between 30–120 Hz to correct the problem area.
±9 dB gain control
Boost or cut as needed to flatten the response curve.
Compatible with measurement tools
Use room measurement tools like REW or XTZ Room Analyzer II Pro to visualize your room’s acoustic response and guide your PEQ adjustments.
Port Tuning - High frequency
With no plugs in the ports the subwoofer will provide a “quick” and “punchy” bass character. It will produce increased output higher up in the frequency range.
Port Tuning - Mid. frequency
If the left port is blocked and the right port is open, this will provide a bass with an increased output in the mid-region.
Port Tuning - Low. frequency
If the right port is blocked and the left port is open, this will provide a deep bass with an increased output in the lower frequencies.
Both ports closed
With both ports blocked the sealed box will provide a dry and controlled bass character.
